Vacuum Drying Oven (Large Capacity)

Vacuum Drying Oven (Large Capacity)(DP810)

Item Code：200000

Model：DP810

Power Source：AC220V 30A

Origin：Japan

Product Summary

Large-capacity type

Features

Decompression drying the large size samples are available. Space-saving type with a vacuum pump can set inside. Control panel with interactive key input, temp. displayed by the LED. Various functions with high accuracy.

Specifications

Item Code

200000

Model

DP810

Method

Vacuum drying by decompressed chamber direct heating

Operating temperature range

Room temp.+40~200℃

Operating pressure range

100 to 0.1kPa（760 to 1 Torr）

Temp. adjustment accuracy

±1℃（at200℃）

Interior Material

Stainless steel

Exterior Material

Cold rolled steel plate with baked-on melamine resin finish

Door

Single swing door

Heat insulating material

Rock wool

Heater

Mica heater, 6.5kW

Operation functions

Fixed temp., Auto-start, Auto-stop, Quick auto stop, Program (max.99 steps, 99 patterns, repeat)

Heater circuit control

Triac zero-cross control

Temp. sensor

K-thermocouple (Double sensor)

Exhaust port

NW40

Inlet/Purge port

RC 1/4

Temp. control method

PlD control by microprocessor

Temp. setting method

Digital setting with UP/DOWN key

Temp display method

Digital display

Other display

Temperature indicating the operation state displayed by LED

Additional functions

Calendar timer (max. 24 Hrs.), Integration time (max. 65535 hrs.), Clock, Calibration off-set, Display the amount of power consumption / CO2 discharge / Heater operation amount,Power failure recovery mode, User setting information save and recall

Safety countermeasures

Self diagnosis functions(Sensor, Heater, Triac, Automatic overheating prevention), Independent overheating prevention,Key lock function, Electric leakage breaker

Internal dimensions（W×D×H mm）

800×800×800mm

Internal capacity

512L

External dimensions（W×D×H mm）

1020×1019×1850mm

Power Source

AC220V 30A

Weight

600kg

Accessories Shelf plate

Punched stainless steel, 2 pcs
