Cooling Water Circulator

Cooling Water Circulator(CFE820)

Item Code：221561

Model：CFE820

Power Source：AC115V/AC220VSingle-phase with step down transformer

Origin：Japan

Product Summary

Features

Specifications

Item Code

221561

Model

CFE820

External dimensions（W×D×H mm）

620×440×600mm

Power Source

AC115V/AC220VSingle-phase with step down transformer

Weight

65kg

Circulation Type

External Closed Circulation

Operating Temperature Range

-20 deg.C to 20 deg.C

Temp. adjustment accuracy JTM K05/ Temp. fluctuation JIS (Load)

±0.5 deg.C (JTM K05) at -20 deg.C / 1.6 deg.C ( JIS) at -20 deg.C

Cooling Capacity

Approx. 1,100W at Liquid temp. 0 deg.C, Approx. 730W (559kcal/h) at Liquid temp. -10 deg.C, Approx. 270W (215kcal/h) at Liquid temp. -20 deg.C

External circulation capacity pump max flow

8.2/9.5L/min (50/60Hz)

External circulation capacity pump head

9.5/13m (50/60Hz)

External circulation system number

1 system

External circulation nozzle

Rc3/8 with stop valves (Hose nipples are optional)

Temp. control

Refrigerator inverter frequency control, Refrigerator ON/OFF operation (depends on the conditions, 3 minutes)

Temperature Sensor

T thermocouple

Temp. setting / display

Digital setting/display

Refrigerator

Air cooling sealed rotary type, 700W

Refrigerant

R407C

Cooling coil material

Nickel plated copper

Circulation pump

Magnet pump 125W

Ambient temperature range (during operation)

5 deg.C to 35 deg.C

Safety functions

Over current electrical leakage breaker, Refrigerator over load relay, Overheating (30 deg.C or more), Refrigerator high pressure relay, Pump thermal protector, Delay timer for protecting refrigerator, H bypass for protecting pump, Inverter overload protecting circuit

Other functions

Drain cock, Dust prevention filter, Water level gauge, Drain pan for overflow/circulation nozzle, Calibration offset function

Water tank Dimensions

W245 x D315 x H184mm

Water tank material

SUS304

Tank capacity

14L (liquid volume 13L)

Accessories

Lid, Drain pan for overflow and circulation
